3.2 mm (0.13 inches), High Transmission, AR Coated Tempered Glass
Junction-Box
IP68, three diodes
Cables
4.0mm² , 300mm in length
Cell Orientation
144cells(6*24)
ELECTRICAL CHARACTERISTICS
Minimum performance at standard test conditions, stc1 (power tolerance 0~+5w)
Model
LR5-72HBD-525M
LR5-72HBD-530M
LR5-72HBD-535M
LR5-72HBD-540M
LR5-72HBD-545M
LR5-72HBD-550M
Max. Power
525
530
535
540
545
550
Open Circuit Voltage
49.05
49.20
49.35
49.50
49.65
49.80
Short Circuit Current
13.65
13.71
13.78
13.85
13.92
13.98
Max. Power Voltage
41.20
41.35
41.50
41.65
41.80
41.95
Max. Power Current
12.75
12.82
12.90
12.97
13.04
13.12
Efficiency²
20.5
20.7
20.9
21.1
21.3
21.5
MECHANICAL DATA
Module Dimensions
2256*1133*35mm
Weight
32.2kg
Glass
3.2 mm (0.13 inches), High Transmission, AR Coated Tempered Glass
Junction-Box
IP68, three diodes
Cables
4.0mm² , 300mm in length
Cell Orientation
144cells(6*24)
ELECTRICAL CHARACTERISTICS
Minimum performance at standard test conditions, stc1 (power tolerance 0~+5w)
Model
LR5-72HBD-525M
LR5-72HBD-530M
LR5-72HBD-535M
LR5-72HBD-540M
LR5-72HBD-545M
LR5-72HBD-550M
Max. Power
525
530
535
540
545
550
Open Circuit Voltage
49.05
49.20
49.35
49.50
49.65
49.80
Short Circuit Current
13.65
13.71
13.78
13.85
13.92
13.98
Max. Power Voltage
41.20
41.35
41.50
41.65
41.80
41.95
Max. Power Current
12.75
12.82
12.90
12.97
13.04
13.12
Efficiency²
20.5
20.7
20.9
21.1
21.3
21.5
MECHANICAL DATA
Module Dimensions
2278*1134*35mm
Weight
32.2kg
Glass
3.2 mm (0.13 inches)
High Transmission
AR Coated Tempered Glass
Junction-Box
IP68
three diodes
Cables
4.0mm²
300mm in length
Cell Orientation
144cells(6*24)
ELECTRICAL CHARACTERISTICS
Minimum performance at standard test conditions, stc1 (power tolerance 0~+5w)
Model
LR5-72HBD-535M
LR5-72HBD-540M
LR5-72HBD-545M
LR5-72HBD-550M
Max. Power
535W
540W
545W
550W
Open Circuit Voltage
49.35V
49.50V
49.65V
49.80V
Short Circuit Current
13.78A
13.85A
13.92A
13.98A
Max. Power Voltage
41.50V
41.65V
41.80V
41.95V
Max. Power Current
12.90A
12.97A
13.04A
13.12A
Efficiency²
20.9%
21.1%
21.3%
21.5%
{"json":"[{\"index\":\"0\",\"tran_label\":\"\"},{\"index\":\"1\",\"tran_label\":\"MECHANICAL DATA\"},{\"index\":\"2\",\"tran_label\":\"Module Dimensions\",\"tran_value\":[\"2278*1134*35mm\"]},{\"index\":\"3\",\"tran_label\":\"Weight\",\"tran_value\":[\"32.2kg\"]},{\"index\":\"4\",\"tran_label\":\"Glass\",\"tran_value\":[\"3.2 mm (0.13 inches)\",\"High Transmission\",\"AR Coated Tempered Glass\"]},{\"index\":\"5\",\"tran_label\":\"Junction-Box\",\"tran_value\":[\"IP68\",\"three diodes\"]},{\"index\":\"6\",\"tran_label\":\"Cables\",\"tran_value\":[\"4.0mm²\",\"300mm in length\"]},{\"index\":\"7\",\"tran_label\":\"Cell Orientation\",\"tran_value\":[\"144cells(6*24)\"]},{\"index\":\"8\",\"tran_label\":\"ELECTRICAL CHARACTERISTICS\"},{\"index\":\"9\",\"tran_label\":\"Minimum performance at standard test conditions, stc1 (power tolerance 0~+5w)\"},{\"index\":\"10\",\"tran_label\":\"Model\",\"tran_value\":[\"LR5-72HBD-535M\",\"LR5-72HBD-540M\",\"LR5-72HBD-545M\",\"LR5-72HBD-550M\"]},{\"index\":\"11\",\"tran_label\":\"Max. Power\",\"tran_value\":[\"535W\",\"540W\",\"545W\",\"550W\"]},{\"index\":\"12\",\"tran_label\":\"Open Circuit Voltage\",\"tran_value\":[\"49.35V\",\"49.50V\",\"49.65V\",\"49.80V\"]},{\"index\":\"13\",\"tran_label\":\"Short Circuit Current\",\"tran_value\":[\"13.78A\",\"13.85A\",\"13.92A\",\"13.98A\"]},{\"index\":\"14\",\"tran_label\":\"Max. Power Voltage\",\"tran_value\":[\"41.50V\",\"41.65V\",\"41.80V\",\"41.95V\"]},{\"index\":\"15\",\"tran_label\":\"Max. Power Current\",\"tran_value\":[\"12.90A\",\"12.97A\",\"13.04A\",\"13.12A\"]},{\"index\":\"16\",\"tran_label\":\"Efficiency²\",\"tran_value\":[\"20.9%\",\"21.1%\",\"21.3%\",\"21.5%\"]}]","type":"2"}
We are the Official Authorized Distributor of LONGl Solar for 9 years.
We promise that all LONGl solar modules are original.
Contact us to get the latest price now! Mob: 0086 181 1880 9916, Email: sales@mogesolar.com
We are the Official Authorized Distributor of LONGl Solar for 9 years.
We promise that all LONGl solar modules are original.
Contact us to get the latest price now! Mob: 0086 181 1880 9916, Email: sales@mogesolar.com
